| Display：TFT |
| Transmission Type：2.4GHz digital frequency |
| Modulation：Digital modulation |
| Polar Pattern：Omnidirectional |
| Antenna：ln-built antenna |
| perating Range(without obstacles)：328' (100m) |
| Sampling Rate：48KHz |
| Frequency Response：20Hz-20KHz |
| Signal-to-Noise Ratio：>80dB |
| Maximum SPL：110dB SPL |
| Sensitivity：-39±2dB |
| Audio Input Connector：TX: In-built condenser microphone |
| Monitoring Connector：RX:3.5mm monitor port |
| Audio Output Connector：RX: 3.5mm auto-sensing output(TRS/TRRS) |
| Power Requirements：ln-built rechargeable lithium-ion battery |
| Battery Specification：TX:3.85V/495mAh / RX:3.7V/1600mAh |
| Charging Connector：Tx: Charging contacts / RX: USB-C |
| Charging Time：RX: Approx.2.5 hours (using 5V/2A charger) |
| Battery Life(TX)：Approx. 5 hours(onboard recording enabled) / Approx.8 hours (onboard recording disabled) |
| Battery Life(RX)：RX:Approx.24 hours(One TX fully charged) |
| Memory：Tx:8GB |
| Weight：TX:1.06oz(30g) / RX:2.47oz(70g) |
| Dimensions：TX: ø1.85×0.49"(ø47×12.5mm) / RX:2.23×2.23×0.99"(56.6×56.6×25.2mm) |
| Operating Temperature：0℃ to +50℃ / -10℃ to +50℃ |
