Designed exclusively for the Nikon Z mount

Optics optimized for the image sensors of mirrorless cameras with the Nikon Z-mount are implemented. The lens has a full-frame image circle and can be used with both full-frame (Nikon FX format) and APS-C size (Nikon DX format) mirrorless cameras.

Apochromatic design

This design thoroughly eliminates various aberrations including axial chromatic aberrations and pursues the ultimate performance in terms of resolution and contrast reproducibility.

Optical glass and mechanical components that deliver high performance

Of the 11 elements in 9 groups in the optical configuration of this lens, 5 elements are made using anomalous partial dispersion glass, 2 elements have aspherical surfaces on both sides, and the lens also employs a floating mechanism.

Information communication with the body by electronic contacts

This lens is equipped with electronic contacts and realizes communications between the lens and the body. In addition to Exif information and in-body image stabilization (3 axes), by combining with a body compatible with communications and the latest firmware*1, three types of focusing support functions ( [1] focusing by color changing of the focus point frame [2] peaking function focusing and [3] focusing with the enlargement button) are supported.

A 12-blade aperture for "blurred ball" expression

The 12 aperture blades, have a special circular shape that attractive, not only at the maximum aperture of F2, but also at a range of smaller apertures. This allows photographers to take full advantage of the " blurred ball " effect of point light sources and other image situations.

Manual focus for reliable focus operation

Adopting a full-metal helicoid unit processed and adjusted with high precision and high-quality grease that produces an appropriate torque, focusing with a smooth operation feeling is realized. It enables fine focus adjustment.

Lens diagram

Focal Length

35mm

Aperture Ratio

1 : 2

Minimum Aperture

F16

Lens Construction

9 groups 11 elements

Angle of View

62.1°

Aperture Blade

12 elements(Circular aperture at F2, F2.8, F5.6 and F16)

Minumum Focus

0.27m

Maximum reproduction ratio

1: 4.47

Diameter×Length

φ68.8×70.4mm

Filter size

φ58mm

Weight

420g

Hood

Reversible bayonet mount hood

Aperture ring

Available (Manual Setting)

Electrical Contact

Available *1

Exif Data

Available *1 *2

Focusing support function 1

Color changing of the focus point frame

Focusing support function 2

Peaking function focusing

Focusing support function 3

Magnification button on camera body

In-body image stabilization

Possible(only on camera with in-body stabilization)

Corresponding sensor size

Full frame
