DIMENSIONS

Interior (L×W×D)

4.37 x 2.87 x 1.68 in (11.1 x 7.3 x 4.3 cm)

Exterior (L×W×D)

5.88 x 4.06 x 2.12 in (14.9 x 10.3 x 5.4 cm)

MEASUREMENTS

Lid Depth

0.69" (1.8 cm)

Bottom Depth

0.94" (2.4 cm)

Total Depth

1.63" (4.1 cm)

Int Volume

0.01 ft³ (0 m³)

WEIGHTS

Weight With Foam

0.41 lbs (0.2 kg)

Weight Empty

0.40 lbs (0.2 kg)

Buoyancy

0.51 lbs (0.2 kg)

MATERIALS

Body Material

Polycarbonate (PC)

Latch Material

Xylex

O-Ring Material

Thermoplastic Rubber

Pins Material

Stainless Steel

Foam Material

TL - 426 4 lb. Esther

Purge Body Material

Polycarbonate (PC)

Purge Vent Material

Polyester Spun-Bond ePTFE Oleophobic

TEMPERATURES

Minimum Temperature

-10° F (-23 ° C)

Maximum Temperature

199° F (93 ° C)

Approvals

Certifications

IP67
