| Order Number |
11194 |
View angle (diagonal/horizontal/vertical)
Full-frame (24 × 36 mm) |
14 mm: 114.2°/102.4°/79.3° | 24 mm: 85.0°/74.6°/53.9° |
| Lens system |
|
| Number of lenses/assemblies |
18/13 |
| Position of the entrance pupil before the bayonet |
14 mm: 96.2 mm | 24 mm: 91.6 mm |
| Focus range |
14 mm: 280 mm to ∞ | 24 mm: 280 mm to ∞ |
| |
|
| Focusing |
|
| Setting |
Choose automatic (Autofocus) or manual mode on the camera |
| Smallest object field |
Full-frame: 14 mm: 273 mm x 410 mm │ 24 mm: 176 mm x 265 mm |
| Largest scale |
14 mm: 1:11.4 │ 24 mm: 1:7.4 |
| |
|
| Aperture |
|
| Setting/Function |
Electronically controlled aperture, setting on the camera, half or third values can also be set |
| Smallest aperture |
22 |
| |
|
| Bayonet |
Leica L bayonet fitting with contact strip |
| Firmware |
Lens firmware can be updated via the camera |
| Coating |
Hydrophobe Aqua-Dura® coating on external lenses |
| Material |
Aluminum full-metal housing, black anodized, dust and splash water protected |
| Filter thread |
Holder for foil filter on bayonet |
| Lens hood |
Permanently mounted |
| |
|
| Dimensions |
|
| Length |
Approx. 131 mm |
| Diameter |
Approx. 85 mm |
| Weight |
Approx. 855 g |
