Order number
Black anodized |
11 192 |
View angle (diagonal, horizontal, vertical)
Full-frame (24 x 36 mm) |
63.0°/53.6°/38.3° |
| Lens system |
0.7m / 2.3' |
| Number of lenses/assemblies |
45605 |
| Number of asph. surfaces |
6 |
| Position of the entrance pupil before the bayonet |
61.8 mm |
| Focus range |
0.24 m to infinity |
| Focusing |
∞ to 0.27 m |
| Setting |
Choose automatic (Autofocus) or manual mode on the camera |
| Smallest object field |
Full-frame: 110 x 165 mm |
| Largest scale |
1:4,6 |
| Diaphragm |
Electronically controlled aperture, set using turn/push wheel on camera, including half and third values |
| Setting/function |
Electronically controlled aperture, setting on the camera, half or third values can also be set |
| Smallest aperture |
22 |
| Firmware |
Lens firmware can be updated via the camera |
| Coating |
Hydrophobe Aqua-Dura® coating on external lenses |
| Material |
Magnesium and aluminum full-metal housing, black anodized, dust and splash water protected |
| Bayonet |
Leica L bayonet fitting with contact strip |
| Filter thread |
E67 |
| Lens Hood |
Male bayonet for lens hood (included in the scope of delivery) |
| Dimensions |
35 mm |
| Length |
Approx. 83 mm/124 mm (without/with lens hood) |
| Diameter |
Approx. 74,5 mm/82 mm (without/with lens hood) |
| Weight |
Approx. 400 g/444 g (without/with lens hood) |
