自然呈現，一見傾心
旁軸系統是每台徠卡M相機的核心。它能提供明亮且非常清晰的視野，帶您領略畫外之景。它可呈現寬廣的取景範圍，讓您精準掌控對焦和曝光。徠卡M6搭載機械旁軸系統，0.72倍取景器放大倍率，由100多個獨立零件手工製作而成。光圈和曝光參數可以通過鏡頭的選擇性曝光測光進行精確設定，而測光參考指示則顯示在取景器的下部。經典黃斑對焦是快速精確對焦的理想之選，即使在低照度情況下也依然出色。
隨時準備迎接決定性瞬間
眼見越廣，應對越佳。徠卡M6的旁軸對焦技術帶您領略畫外之景，助您準確抓住快門時機。成像框線提示突出了六個焦段的成像範圍，它們成對組合，分別為28和90毫米、35和135毫米，以及50和75毫米。裝上鏡頭後，相應的焦段取景範圍會自動出現在取景器中，成為框線。此外，使用框線選擇器撥杆可將其他所有框線顯示在取景器中。在按下快門之前，您可以根據拍攝物件選擇合適的焦段，在決定性時刻捕捉畫面。
標誌性設計
數十年來，M相機不僅創造出各種標誌性影像，它們本身也成為了一種標誌性相機。簡潔優雅、堅實可靠和高品質材料彙聚而成的標誌性設計久經時間考驗，定義了每一台徠卡M相機。M6相機採用了高度防刮漆面、實心黃銅頂蓋和耐用的皮革材質。此外，玻璃元件表面帶有防反射塗層，可防止散射光干擾。新一代相機還延續了1984年原版相機上紅色Leitz標誌的設計。
真值永存
潮流起起落落，但真正的價值經得起時間的考驗，代代流傳。徠卡相機和徠卡鏡頭是耐用性、可靠性和高品質等傳統價值的證明。它們代表了實實在在的品質，背後蘊藏著高級的材料和可靠的技術。徠卡一直致力於手工製造精密設備，開發首屈一指的機械和光學傑作，不斷樹立新標準。“德國製造”帶來的實在的品質，只為給您時刻極致的攝影自由。
| Designation | Leica M6 |
| Camera type | Analogue rangefinder system camera (35 mm) |
| Type No. | 2248 |
| Order No. | Black: 10 557 |
| Material | Closed full metal housing, Top cover and bottom cover: brass, black finish |
| Lens mount | Leica M bayonet |
| Operating conditions | 0°C to +40°C |
| Interfaces | ISO accessory shoe |
| Tripod thread | A 1⁄4 DIN 4503 (1⁄4”) with stainless steel in the base |
| Dimensions | 138 x 40 x 77 mm |
| Weight | 575 g (without battery) |
| Viewfinder | Large, bright-line rangefinder with automatic parallax compensation |
| Parallax compensation | The horizontal and vertical difference between viewfinder and lens is compensated automatically in line with the relevant focus setting. Congruence of viewfinder and actual image. The size of the bright-line frame matches the distance: – at 2 m: the exact sensor size of approx. 23.9 x 35.8 mm – at infinity: (depending on focal length) approx. 7.3% (28 mm) to 18% (135 mm) – less than 2 m: less than film size |
| Viewfinder magnification | x0.72 (all lenses) |
| Wide- base rangefinder | Split and superimposed image rangefinder shown as a bright field in the center of the viewfinder image. |
| Shutter | |
| Shutter type | Focal plane shutter with rubber liner, mechanically controlled |
| Shutter speeds | Mech. shutter: 1 s - 1⁄1000 s Flash Synch: up to 1⁄50 s |
| Shutter release | Two-stage: Power up (activation of exposure meter) – Release. Integrated standard cable release thread. |
| Film winding | |
| Loading | Manual with quick wind lever or LEICAVIT M, motorized with LEICA MOTOR-M, LEICA WINDER-M, LEICA WINDER |
| Rewinding | Manual with telescopic rewind knob |
| Frame counter | On top of camera. Automatic reset after removal of bottom cover. |
| Focusing | |
| Working range | 70 cm to ∞ |
| Focus mode | Manual |
| Exposure | |
| Exposure metering | TTL (exposure metering through the lens), with working aperture |
| Metering cell | Silicon photo diode with convex lens to the top left behind the camera bayonet. |
| Film speed range | Manual setting from ISO 6/9° to ISO 6400/39°. |
| Metering principle | The light reflected by a metering spot in the center of the 1st shutter curtain is metered. The metering spot has a diameter of 12mm and therefore corresponds to approx. 13% of the full negative format or around 2/3 of the short side of the corresponding frame in the viewfinder. |
| Exposure control mode | Manual shutter speed and aperture setting, adjustment using LED light balance. |
| Flash | |
| Flash unit connection | Via accessory shoe |
| Synchronisation | On the 1st shutter curtain |
| Flash sync speed | 1/50s; slower shutter speeds possible. |
| Flash exposure control | Via computer control of flash unit or via guide number calculation and manual setting for the required aperture. |
| Power Supply | 2 Silver oxide button cells (PX76/SR44) or 1 Lithium battery (DL1/3N) |
