Computer Interface

USB Type‑C.

Bluetooth

Bluetooth 5.1 LE

Software Updates

1 x USB‑C for firmware updates.

Camera Selection buttons

8 x NKK buttons.

Assignable via setup utility.

Camera Number Display

Green off air, red on air.

Setup

White and black balance setup.

Flare via modifier key.

3 Axis Joystick

1

Preview Button

1

Iris Control

Auto Iris On, Coarse control.

Iris Range

CLS f32 to f1.2

Gain Range

-12dB to +32dB

ND Filters

0, 2, 4, 6.

Shutter Range

1/24 to 1/2000

White Balance Range

2500K to 10,000K

Recallable Scenes

5 per camera.

Panel Active

Protects settings.

Software Applications

ATEM Micro Panel controls ATEM Software Control Panel running on the host computer.

Mac 14.0 Sonoma,
Mac 15.0 Sequoia or later.

Windows 10 and 11.
Windows 11 for ARM

Power Supply

Internal battery with power switch.

USB-C port for external power supply and battery charging.

Power Usage

4 W max.

Battery Life

Minimum 3 hours.

(under normal use)

Operating Temperature

5° to 40° C (41° to 104° F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing

ATEM Micro Camera Panel

Welcome wallet with QR code for software download

1 x USB‑C cable

1 Year Limited Manufacturer’s Warranty.
