Redefining Fast
TRIBEX Hydraulic Tripod Kit
Innovative Patented X-CLUTCH Hydraulic Technology
Speed is Key
Patented Clutch Design with single-action leg deployment and self-locking
Born to Be Pro
4-Step Counterbalance with Up to 6kg / 13.2lbs Payload
Ultimate Portability
Designed to Fit a 28" Luggage 66cm / 26in Tripod Storage Length
Balancing in Seconds
Set up and level your camera in one smooth motion
*The hydraulic structure remains stable from -20°C to 65°C / -4°F to 149°F
Quality Tested
10000+ Tilt and pan tests with consistent damping force 20000+ Tripod leg extension and locking tests, maintaining secure load-bearing capacity
Intuitive CLUTCH Design
Ergonomically shaped X-Clutch ensures effortless control and comfortable one-handed operation
0° Storage
45° Grip
90° Operation
Smooth Movement Experience
4-Step Dynamic Counterbalance with Up to 6kg / 13.2lbs Payload
Consistent Pan and Tilt Damping
Fine-Tune Damping with One Full Twist
Detachable Center Column for Ultra-Low Shooting
27cm to 168cm / 10.6in to 66.14in Working Height
Expanded Capabilities
Expanded Capabilities
①Tilt Locking Knob ②Tilt Damping Adjustment Knob ③Pan Damping Adjustment Ring ④QR Plate ⑤Pan Handle Locking Knob ⑥Reversible Pan Bar ⑦Dynamic Balance Adjustment Knob ⑧Bubble Level ⑨Pan Locking Knob
Compatible with Manfrotto and DJI RS series quick release plates
Easy to Expand with Accessories
Outstanding Combination
Ergonomic Knob
Flat Feet with Built-in Metal Spikes
Backpack-Style Storage Bag
2-in-1 Quick Release Hook and Allen Wrench
Hidden Flat Wrench
Screw Storage
Ergonomic Knob
Flat Feet with Built-in Metal Spikes
Backpack-Style Storage Bag
2-in-1 Quick Release Hook and Allen Wrench
Hidden Flat Wrench
Screw Storage
Product List and Specifications
SmallRig x Potato Jet TRIBEX Hydraulic Carbon Fiber Tripod Kit
ID 4259
Package Tripod Kit x 1 Allen Wrench x 1 Guarantee Card x 1 Storage Bag x 1 Smartphone Holder x 1 Product Dimensions: 790.0 x 140.0 x 120.0 mm / 31.1 x 5.5 x 4.73in Package Dimensions: 880.0 x 175.0 x 175.0mm / 34.6 x 6.9 x 6.9in
| Product Weight: |
3.8 ± 0.1kg / 8.4 ± 0.2lb |
| Package Weight: |
5.5 ± 0.1kg / 12.1 ± 0.2lb |
| Working Height: |
27.0 - 168.0cm / 10.6 - 66.1in |
| Storage Length: |
79.0cm / 31.1in |
| Tilt Range: |
90° / -65° |
| Counterbalance Payload: |
0 - 6.0kg / 0 - 13.2lb |
| Counterbalance Step: |
4-Step (0, 1, 2, 3) |
| Tilt Control: |
Stepless |
| Pan Control: |
Stepless |
| Handle Length: |
23.0 - 36.0cm / 9.0 - 14.2in |
| Leg Section: |
3 |
| Leg Tube Diameter: |
29.5mm / 25.5mm / 22.0mm; 1.16 / 1.0 / 0.87in |
| Base Diameter: |
65.0mm / 2.56in |
| Center Column Base Diameter: |
60.0mm / 2.4in |
| Angle Adjustment: |
23°, 55°, 81° |
Material(s):
Carbon Fiber, Aluminum Alloy, POM, Stainless Steel, Silicone |
Note:
1.Before shooting, make sure the head and tripod locking status are in normal condition.
2.Avoid use in sandy or dusty environments to prevent the risk of damage.
3.After using the short center column, mounted on the center column, need to ensure that the locking status
4.Max payload of head: 6kg / 13.2lb (center column raised, leg angle at 23°, height at 168cm / 66.1in).
5.The weight capacity of the tripod head is not the absolute limit; it varies depending on the type of equipment, lenses used, accessories attached, and changes in the center of gravity.
6.Max payload of tripod: 25kg / 55lbs (center column not raised, tripod head detached, leg angle at 23°, height at 141cm / 55.5in).
7.After soaking in water, it needs to be dried before use.
