| SPECIFICATION |
| Effective Sensor Size |
18.96mm x 10mm (Four Thirds) |
| Lens Mount |
Active MFT mount. |
| Lens Control |
Iris, focus and zoom on supported lenses. |
| Dynamic Range |
13 Stops. |
| Dual Native ISO |
400 and 3200 |
| Shooting Resolutions |
4096 x 2160 (4K DCI) up to 60 fps
4096 x 1720 (4K 2.4:1) up to 75 fps |
| Frame Rates |
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.
Off-speed frame rates up to 60 fps in 4K DCI, 120 fps in 2.6K 16:9 and HD windowed. |
| Focus |
Auto focus available using compatible lenses. |
| Iris Control |
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses. |
| Screen Dimensions |
5” 1920 x 1080. |
| Screen Type |
LCD capacitive touchscreen. |
| Metadata Support |
Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes. |
| Controls |
Touchscreen menus on 5 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push integrated into handgrip, 1 x ISO Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button, 1 x Play Button, 1 x Focus Button and 1 x IRIS Button. |
| Media |
1 x CFast card slot, 1 x SD UHS-II card slot, 1 x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and ProRes Recording. |
| Media Format |
Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
| Dimensions |
178.1 x 85.5 x 96 mm |
| Weight |
722 g |
| What's Included |
| Blackmagic Pocket Cinema Camera 4K, Lens turret dust cap, 30W power supply with locking connector and international adapters, LP‑E6 battery, SD card with software and manual, Welcome card, DaVinci Resolve Studio with activation key |
